NOSHOK 2070-MFS-P2

NOSHOK 2070 2-Valve Electropolished 316 Stainless Steel Block and Bleed Hard Seat Needle Valve, 1/2 in MPT x FPT, 10000 psi, Grafoil Packing

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK
  • Tipco Part No: NOS 2070-MFS-P2
  • MPN: 2070-MFS-P2
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK Block and Bleed Hard Seat Needle Valve, 2070 2-Valve Series, Nominal Size: 1/2 in, Connection Type: MPT x FPT, 316 Stainless Steel, 316 Stainless Steel Stem, Graphite Packing Trim, FKM/PTFE Seal, Flow Coefficient: 0.44 Cv, Finish: Electropolished, 4 in Length, 5-17/32 in Height, 200 deg F, 10000 psi

California residents see Prop 65 WARNINGS

Product Type      :      Needle Valve
Series      :      2070 2-Valve
Nominal Size      :      1/2 in
Connection Type      :      MPT x FPT
Material      :      316 Stainless Steel
Trim Material      :      316 Stainless Steel Stem, Graphite Packing
Seal Material      :      FKM/PTFE
Flow Coefficient      :      0.44 Cv
Finish      :      Electropolished
Length      :      4 in
Height      :      5-17/32 in
Temperature Rating      :      200 deg F
Pressure Rating      :      10000 psi
  • Combines isolating and venting in a single valve, eliminating the need for tubing and fittings
  • Block valve isolates the downstream process fluids and the bleed valve exhausts upstream fluids enabling instruments to be removed without disturbing the permanent piping installation
  • The 1/4 in NPT vent plug is located 90 deg to the left and may be removed and replaced with exhaust piping to direct the fluids to a safe location
  • 100% helium leak tested to 1 x 10-4 ml/s for performance and reliability
  • Blowout-proof stem provides a secondary stem seal in the full open position
  • FKM O-ring seal and PTFE back-up ring below the stem threads to protect from corrosion and galling
  • All stem threads are rolled for strength and ease of operation
  • 1-piece bonnet with a metal-to-metal seal to the valve body below the bonnet threads
  • Slotted spring pin to prevent accidental loosening
  • Vinyl dust cap for bonnet and stem
  • Made in USA
