OPW® VISI-FLO® Sight Flow Indicator, 1400 Series, Connection Size: 3 in, Connection Type: Flange, 200 psi, -20 to 250 deg F, Annealed Soda Lime Glass Window, Neoprene Seal, Delrin Indicator
| Product Type | : | Sight Flow Indicator |
| Series | : | 1400 |
| Connection Size | : | 3 in |
| Connection Type | : | Flange |
| Pressure Rating | : | 200 psi |
| Temperature Rating | : | -20 to 250 deg F |
| Window Material | : | Annealed Soda Lime Glass |
| Seal Material | : | Neoprene |
| Indicator Material | : | Delrin |
OPW® Engineered Systems has been manufacturing sight flow indicators for more than 60 years. Our experience has led to many innovations in design and manufacturing, making VISI-FLO® the most thoroughly engineered sight flow indicator on the market. VISI-FLOs are available in two Series the standard 1400 Series and the 1500 High Pressure/High-Temperature Series.
- An innovative radial seal creates a constant and uninterrupted sealing force between the body and outside diameter of the glass lens for a longer-lasting and better seal than conventional flat seals
- Bolt-on-body design requires no special maintenance or torqueing sequence in order to prevent leaks, resulting in safer operation than units using tie rods to fasten the lens and seal to the body
- Feature end-to-end dimensions that match Jacoby-Tarbox and Penberthy and other manufacturer's units
- Rated for vacuum service up to 635 mm at 85.5% vacuum, which equates to 12.3 psi vacuum
- Drip tube, propeller, bi-directional flapper, bi-directional plane
Applications: For power plant, waste water treatment, petroleum industry, chemical industry, manufacturing, OEM markets
