NOSHOK 623-2-1-1-2-6

NOSHOK 623 Non-Incendive Pressure Transmitter, 1/4 in MPT, 0 - 2 psig, 4 - 20 mA, 2-Wire Output

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK
  • Tipco Part No: NOS 623-2-1-1-2-6
  • MPN: 623-2-1-1-2-6
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK Non-Incendive Pressure Transmitter, 623 Series, Pressure Range: 0 - 2 psig, Process Connection: 1/4 in MPT, Electrical Connection: 1/2 in MPT Conduit with 6 ft Integral Cable, +/-0.25% Full Scale (BFSL) Accuracy, Output Signal: 4 - 20 mA, 2-Wire, Power Required: 10 - 30 VDC, Response Time: <=1 ms, -22 to 176 deg F Ambient, -40 to 212 deg F Media, -22 to 212 deg F Storage, 316 Stainless Steel, Enclosure: IP65/67, Dimensions: 1.06 in Dia x 4.25 in L

California residents see Prop 65 WARNINGS

Product Type      :      Pressure Transmitter
Series      :      623
Pressure Range      :      0 - 2 psig
Process Connection      :      1/4 in MPT
Electrical Connection      :      1/2 in MPT Conduit with 6 ft Integral Cable
Accuracy      :      +/-0.25% Full Scale (BFSL)
Output Signal      :      4 - 20 mA, 2-Wire
Power Required      :      10 - 30 VDC
Response Time      :      <=1 ms
Temperature Rating      :      -22 to 176 deg F Ambient, -40 to 212 deg F Media, -22 to 212 deg F Storage
Material      :      316 Stainless Steel
Enclosure      :      IP65/67
Dimensions      :      1.06 in Dia x 4.25 in L
  • Vacuum and compound ranges through 0 - 15000 psi, absolute ranges from 0 - 15 psi through 0 - 100 psi
  • 316 stainless steel and elgiloy wetted parts
  • Stability <= +/-0.2% full scale per year, non-accumulating
  • Service life - >100000000 load cycles
  • Load limitations <= (Vpower-10)/0.02 A
  • Proof pressure 3 times full scale
  • Burst pressure 3.8 times full scale
  • Measuring element 316 stainless steel
  • Electrical protection reverse polarity, over-voltage and short circuit protection
  • Shock 1000 g according to IEC 60068-2-27
  • Vibration 20 g according to IEC 60068-2-6

Applications: Ideal for applications including chemical processing, gas pressure measurement, oil field and offshore, mining and well head measurement
