Continental 20146787

Continental FLEXAGrip™ 20146787 Blue Chemivic™ Synthetic Rubber Push-On Multi-Purpose Hose, 1 in, 500 ft L, 300 psi

  • Manufacturers: Continental Industries
  • Brand Name: Continental
  • Tipco Part No: CTI INSTAGRIP BLUE PLUS 1IN
  • MPN: 20146787
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Continental FLEXAGrip™ Push-On Multi-Purpose Hose, Nominal Size: 1 in, 1.34 in OD, 1 in ID, 500 ft Length, 300 psi, Chemivic™ Synthetic Rubber, Carbryn™ Synthetic Rubber Cover, Construction: 1-Braided High-Strength Synthetic Yarn, Blue, 8 in Bend Radius, Resistance Properties: Abrasion, Heat, Oil, Weather, -40 deg F Low, 210 deg F High

Product Type      :      Multi-Purpose Hose
Nominal Size      :      1 in
Outside Diameter      :      1.34 in
Inside Diameter      :      1 in
Length      :      500 ft
Pressure Rating      :      300 psi
Material      :      Chemivic™ Synthetic Rubber
Cover Material      :      Carbryn™ Synthetic Rubber
Construction      :      1-Braided High-Strength Synthetic Yarn
Color      :      Blue
Bend Radius      :      8 in
Resistance Properties      :      Abrasion, Heat, Oil, Weather
Temperature Low      :      -40 deg F
Temperature High      :      210 deg F
  • Chemivic™ oil- and heat-resistant synthetic rubber ARPM class A (high oil resistance) construction tube
  • Carbryn™ rubber cover, ARMP Class A (high oil resistance)
  • Made in USA

Applications: For push-on fittings at maximum working pressures of 400 psi, for low-pressure hydraulic pneumatic systems such as robotics, shop air systems, general industrial, maintenance and automotive assembly applications
