Aeroquip® 3E80-06

Aeroquip® 3E80 Orange Nylon High-Pressure Non-Conductive Hose, 0.38 in, 4050 psi

  • Manufacturers: Eaton
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 3E80-06
  • MPN: 3E80-06
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® High-Pressure Non-Conductive Hose, 3E80 Series, Dash Size: 06, 0.77 in OD, 0.38 in ID, 4050 psi, SAE Rating: SAE 100R8, Nylon, Polyurethane Cover, Construction: Braided Synthetic Fiber, Orange, 2-1/2 in Bend Radius, -65 deg F Low, 212 deg F High

Product Type      :      Non-Conductive Hose
Series      :      3E80
Dash Size      :      06
Outside Diameter      :      0.77 in
Inside Diameter      :      0.38 in
Pressure Rating      :      4050 psi
SAE Rating      :      SAE 100R8
Material      :      Nylon
Cover Material      :      Polyurethane
Construction      :      Braided Synthetic Fiber
Color      :      Orange
Bend Radius      :      2-1/2 in
Temperature Low      :      -65 deg F
Temperature High      :      212 deg F
  • Less than 50 uA leakage when subjected to 75000 V/ft for 5 min

Applications: For general hydraulic systems that may contact high voltage sources, aerial equipment, mobile hydraulics, rescue tools
